Conair 150 - To Start Drying

To Start Drying
1 Make sure there is material in the hopper.
2 Turn on the main power to the dryer. Make sure
the dryer’s disconnect dial is in the ON position. This
powers up the control and the display lights will illu-
minate.
3 Set the drying temperature. Press the appropriate
Select Category button then the Adjust Setpoint (+) or
(-) buttons or enter the temperature on the numeric
keypad and press enter.
(continued)
When configured as a central dryer, the drying temperature
can not be set since there is no process heater in the system.
NOTE: When changing a setpoint use the Select Category Key
directly below the value to be changed. Once pressed the value
will blink, then use the keypads or (+) (-) adjustment setpoints
to enter the new value. Then press enter for the new value to
be recognized.
✐
Operation l 4-37
4
Operation
Setpoint
adjustment
buttons
Select
Category
buttons
