To Start Drying
(continued)
4 Press the START button.
If everything is installed correctly:
• The green light on the start button will illuminate.
• The process and regeneration blowers turn on and the display LEDS
will illuminate.
• The process and regeneration heaters turn on and the display LEDs will
illuminate.
• The desiccant wheel starts turning.
To Stop Drying
1 Press the STOP button. The Stop LED blinks red.
• The blowers continue running for a few minutes
to cool the heaters.
2 Be sure to disconnect and lockout the
main power if you have stopped the dryer to
perform maintenance or repair.
IMPORTANT: Do not use the main power switch to
stop the dryer. Turning off power to the control
and dryer during normal operation prevents the
necessary cool-down period, and can trigger the
shut down/high temperature alarm during your
next drying cycle.
Caution: Improper shut down can cause damage to your dryer.
4-38 l Operation
• The green light on the start button will illuminate.
• The process and regeneration blowers turn on and the dis-
play LEDS will illuminate.
• The regeneration heater turns on and the display LED will
illuminate.
• The desiccant wheel starts turning.
