Screen
SCREEN 3 (Default Screen)
(continued)
SCREEN 4
SCREEN 5
PROCESS TEMPERATURE
ACT 325°F SET 325°F
SETUP, PROC, PROC, PROC, PROCESS
TEMPERATURE RANGE screen 39. The
display will return to the default screen
from anyplace in the menu structure (with
the exception of the AUTOTUNE screens)
if nothing is done after 10 minutes.
Pressing the MENU button from anyplace
in the menu structure will also return to
the default screen.
Shows the regeneration air setpoint and
actual temperature. The setpoint can be
changed with the correct password.
NOTE: Lowering the regeneration setpoint
decreases the capacity of the dryer and nor-
mally is not recommended. Use the dew-
point control function instead.
Shows the actual return air temperature
measured at the inlet to the process blow-
er. If the optional aftercooler flow control
is installed, a setpoint will be displayed on
this screen. The setpoint can be changed
with the correct password.
REGENERATION TEMP
ACT 350°F SET 350°F
RETURN AIR TEMP
ACT 100°F SET 100°F
Function
4-12 l Operation
Control Function Descriptions(continued)
When supplied for
central drying appli-
cations, this function
is not available.
✐
