Screen
SCREEN 13
SCREEN 14
SCREEN 15
DRYER STATUS
PROC REGEN OTHER
DRYER PROCESS
STATUS SCREEN
This is the Dryer Status screen. It can be
found by pressing the Select Category but-
ton under the word "Stat" on the Main
Menu (screen 12). Any information under
the status section is read only; NO
CHANGES can be made from the status
sections. The operator can select to see
status information for Process,
Regeneration, or Other.
This is a column title screen. To navigate
to screens within a column (reference the
flow charts beginning on Page 4-4), the
operator must use the scroll buttons,
“Next” or “Prev”. The “Next” button will
scroll one screen at a time down a list of
screens. Once the last screen in the list is
displayed the “Next” button will return the
operator back to this Title screen. When
the “Prev” button is pressed, it will scroll
one screen at a time up the list of screens.
Once the title screen is displayed the
“Prev” button will go up to the next high
screen, in this case the Dryer Status screen
13.
This is an example of a Heater Output
screen. It displays the actual percentage
output of the heater, which can also be
interpreted as the percentage on time. The
on time can be checked by looking at the
heater LED’s in the Dryer Status section
of the display.
PROCESS HEATER
OUTPUT 100%
Function
4-14 l Operation
Control Function Descriptions(continued)
When supplied for
central drying appli-
cations, this function
is not available.
