Screen
SCREEN 27
SCREEN 28
SCREEN 29 (Regeneration Outlet
Temperature)
SCREEN 30
Function
SETBACK RETURN TEMP
ACT 140°F SET 140°F
SETBACK TEMP BAND
SET 20°F
REGEN OUTLET TEMP
ACT 280
4-18 l Operation
Control Function Descriptions(continued)
MODEL CP150
480 V 60 Hz
This screen shows the actual temperature
measured at the hopper outlet and the set-
point temperature for the air at the hopper
outlet that will initiate the control to go
into setback.
This shows how much lower the hopper
outlet temperature must drop from the
Setback Return Temperature setpoint
(screen 27) before the dryer control should
restore the original process setpoint.
This screen shows the actual temperature
measured at the regeneration outlet of the
desiccant wheel manifold.
This screen shows the model number, volt-
age, and frequency for which the dryer
control is setup. These values can be
changed with the proper password see
page 4-32 (screen 85) under SETUP,
OTHER, INSP, Model # (screen 78), and
Voltage FREQ (screen 80).
