Cleaning the Aftercooler Coils
5 Clean the assembly using a mild soap and water. Let the assembly
dry thoroughly before installation. In severe situations, steam cleaning
or use of solvents maybe necessary.
CAUTION: During the cleaning process, DO NOT cut or remove the
stainless steel wire that holds the assembly together.
6 Inspect the condition of the gasket. If it is damaged, replace the
gasket.
7 Reassemble by repeating the steps in reverse order.
8 Connect the water supply line to the inlet. If a manual shut off
valve is used, it should be mounted on the inlet line as well.
9 Connect the outlet of the aftercooler to the inlet of the flow control
valve using the pre-shaped copper tubing and compression fittings
provided.
Maintenance l 5-11
5
Maintenance
