Hadron/ Hadron DM Carrier
Users Guide
www.connecttech.com
Document: CTIM-00088
Revision: 0.08
Page 41 of 41
Date: 2024-05-15
Additional Feature:
One Power/Wake connector has been added to wake the device from sleep or shutdown mode.
Function
Description
Location
P13
Type
1x2 TH 1.25mm (Molex –
PicoBlade) connector
Pin
Description
1
SYS.SLEEP/WAKE
#
2
GND
