3.3.1 Settings menu
The settings menu contains a view of all user settings of the ST450EC gas detector.
To activate the settings menu:
 Highlight SETTINGS in the main screen of the user menu and press
 The display shows the following information (max. 4 lines simultaneously):
SN. 18-000000
▲
Type: O2 ▼▼
RANGE:
25.0
UNITS:
Vol.%
LOW:
19.0
HIGH:
18.0
SPAN:
20.9
ZLOCK:
0.5
SOFTWARE INFO
OUTPUT
SENS OUTPUT
← BACK
▼
o SN: Serial number
o TYPE: Sensor/gas type
o RANGE: Measurement range
o UNITS: Measurement unit (ppm/ppb/LEL/Vol. %)
o LOW: Set point low alarm level
o HIGH: Set point high alarm level
o SPAN: Set point span gas
o ZLOCK: Zero lock activation
o SOFTWARE INFO: Software version
o OUTPUT: Signal output of the sensor in nA or µA
 To view or change a setting, highlight the desired setting by pressing the
or button and press to select this setting.
 The LCD display shows max. 4 lines, scroll up or down by pressing the
and buttons to show the other settings.
