Contex SD3600 - Scanner Controller Board Layout (SULG)

2-10
Design
J8, Power supplyJ3, MotorJ2, USBJ 5, AUX
J4, Sensors
J7, Keypad
J13, CIS element E
J14, CIS element A
J12, CIS element D
J11, CIS element C
J10, CIS element B
Scanner Controller Board Layout (SULG)
