3-4
Troubleshooting
Error codes displayed on Keypad
Flash code DIAGNOSTIC PAPER
BOOT F F
ERR_GENERAL F OFF
ERR_SU F F
ERR_CB F 2 x F
ERR_MDA F 4 x F
ERR_SMC F 5 x F
Error Codes displayed on the Keypad
An error condition is indicated by a ashing Diagnostic Indicator. The error may be identied
by an Error Code Number being displayed on the screen and/or by the following combinations
of ashing (F) indicators on the Operator Panel:
See Appendix D for error code description.
1 x F, 2 x F, ... means that the Paper Indicator ashes 1, 2, ... times every
time the Diagnostic Indicator is turned ON.
F, F, means that both indicators are ashing simultaneously.
