4-12

Part replacement

Power Supply (SMPS)

2

2. Disconnect ribbon cable for

keypad

3

3. Remove screws (Torx 10)

1

1. Remove Screws (Torx 20)

and gently remove cover

Turn the off scanner and disconnect the power cord

Prerequisites

CAUTION THE POWER SUPPLY IS

DOUBLE POLE/NEUTRAL FUSING

Caution
