4-11
Part replacement
Fig Part no. Description
Service parts
1-01 5398A001 SULG controller board
2-01 0080A074R01 Power Supply (SMPS)
2-02 5398A003 Stepper Motor Assy
2-03 0075A050R01 Tacho Sensor
3-02 0075A160R01 Paper/Lid Sensor (1 pcs.)
N/A 5398A002 Complete CIS Unit (excl. mainboard)
N/A 5231D001R01 IBCA, Interconnection board C (keypad)
2-04 0007S050R0 Power Entry Module
2-05 0090B087R01 USB cable/connector
1-02 5398A005 RHS Cover Assy, Contex (incl Keypad)
2-06 5398A006 Damper Assy. for CIS Bridge
3-01 5398A004 Pressure Rollers (5 pcs.)
1-03 5398A007 LHS End Cover
N/A 0601A005R01 Castors (4 psc.)
N/A 5398A011 Basket Assy.
Consumables
3-03 5398A008 Glass Plate
N/A 5398A010 Calibration Sheet
Part list
