Contex SD3600 - Damper for CIS Bridge

4-23
Part replacement
Damper for CIS Bridge
Turn the off scanner and disconnect the power cord
Open CIS Unit, see page 4-10
Remove LHS Cover, see page 4-9
Prerequisites
2
1. Loosen screws to release clamp.
1
1. Remove Spring
Replace the Damper Assy. and reverse the
steps.
Don’t forget to tighten the Clamp !
3
1. Remove knots and pull out Damper
Assy.
4
