Appendix A
WIDEsystem Service, walk though
Since this chapter is not scanner specic, some of the illustrations may not apply completely to the scanner you are
working on, like number of Cameras and transition areas.
Widesystem / Service consist of 17 different tests designed to help you service the scanner. These test are divided on
5 different tabs according to what you are doing on the scanner.
Paper Path/Handling
Image Quality
Electrical
Utilities
Post Replacement
Some of the tests may appear on or more tab’s. Each test is also associated with a number for easy reference.
No. Name. Tab.
1 Set Serial no. (Post Replacement)
2 Operator Panel LED Test (Electrical, Post Replacement)
5 Lamp On/Off (Image Quality, Electrical, Post Replacement)
6 Motor Test (Electrical, Post Replacement)
9 Oscilloscope View (Image Quality, Post Replacement)
11 Manual Camera (alignment & Stitching) (Image Quality)
12 Manual Scaling (Image Quality, Post Replacement)
20 Streak / Noise Test (Image Quality)
28 Adjust ATAC Sensors (Paper Path/Handling, Post Replacement)
30 Calibrate ATAC (Paper Path/Handling, Post Replacement)
31 Lamp and Fan Test (Electrical, Post Replacement)
42 Backup Calibration and Statistics (Utilities)
43 Restore Calibration and Statistics (Utilities, Post Replacement)
44 License System (Utilities, Post Replacement)
45 Operator Panel Key Test (Electrical, Post Replacement)
46 Paper Sensor Test (Paper Path/Handling, Post Replacement)
