Test 12. Adjust Y-axis Scaling
Here can you adjust the X and Y scaling.
Scan a known size image measure in Nextimage, compare and adjust.
The correction is done in % of the deviation.
Test 11. Stitching & Vertical Align.
Allow you to adjust either Alignment or Stitching between 2
Camera’s modules.
1) Select Alignment or Stitching
2) Select the transition area (AB, BC.....)
3) Use the arrows to either increase or decrease the value
