EMS-96 Instruction Manual IM1200-U v1.6 Pag. 44 / 48
Timed
The selected measures will be sampled at intervals from 1 second to once a month, but only in the days and times set by the
user in order to avoid unnecessary log.
Setup  Log  Timed
Timed Log (Option)
Range
Default
Enable
yes / no
no
Enable or disable the timed log. Before to enable the log functionality, it’s necessary to disable any other activated log.
It is possible to use only one type of log at a time.
Sampling
1sec / 2sec / 3sec / 5sec / 6sec / 10sec / 12sec / 15sec / 20sec / 30
sec / 1min / 2min / 3min / 5min / 6min / 10min / 12min / 15min /
20min / 30min / 60min / end of day / end of week / end of month
15 min
Acquisition timing.
Storage Type
FIFO / end memory
end memory
Type of storage. Note: FIFO after 10 consecutive cycles is automatically disabled.
Start hour
0 ÷ 23
0
Start time of log.
Start minute
0 ÷ 59
0
Start time of log.
End Hour
0 ÷ 23
23
End time of log.
End minute
0 ÷ 59
59
End time of log.
Monday
yes / no
no
Enable or disable the log in this day of the week.
………………..
………………..
Sunday
yes / no
no
Enable or disable the log in this day of the week.
Group 1
See Acronym Group table
---
Selection of the group for the 1
st
measure sampled for the timed log.
Measure 1
See acronym in the table of the group selected
---
Selection of the 1
st
measure sampled for the timed log.
………………..
………………..
Group 15
See Acronym Group table
---
Selection of the group for the 15
st
measure sampled for the timed log.
Measure 15
See acronym in the table of the group selected
---
Selection of the 15
st
measure sampled for the timed log.
Warning: All recordings for all log will be lost if any parameter is changed.
Example: Setup  Log  Timed Sampling 15 min
Storage type end memory
Start hour 8
Start minute 15
End hour 17
End minute 45
Monday yes
Tuesday yes
Wednesday yes
Thursday yes
Friday yes
Saturday no
Sunday no
Group 1 avrage
Measure 1 AVG W
Group 2 avrage
Measure 2 AVG VAr
Enable yes
To display how many log were acquired and the remaining storing time:
Info  Log summary  Timed.
To display the single log:
Info  Log detail  Timed.
