0 - Coast to stop
Wheneither the Enable, Run Forward or RunReverse terminals are opened, the Drive
output is disabled and the motor coast to stop. The Drive cannot be re-enabled for 2
seconds after the Disable/Stop command.
1 -Ramptostop
The Drive ramps down to zero speed under the ramp control selected by parameter
30. The Drive waits for 1 second with the output enabled before disabling.
2 -Ramptostopwith1secondDCinjectionbraking
The Drive ramps down to zero speed under the ramp control selected by parameter
30. The Drive then injects DC for 1 second before the output is disabled.
3 - DC injection braking with detection of zero speed
The Drive injects a low speed currentand detects when the motor is at lowspeed. The
Drive then injects DC for 1 second.
OFF - fixed linear voltage-to-frequency ratio (constant torque - standard load).
On - voltage-to-frequency ratio dependant on load current (dynamic/variable torque -
fan / pump load).
0 - Catch a spinning motor software disabled
1 - Catch a spinningmotor software enabled,detectpositive and negative frequencies
2 - Catch a spinning motor software enabled, detect positive frequencies only
3 - Catch a spinning motor software enabled, detect negative frequencies only
OFF - negative logic enabled (source). Connect 0V to a digital input to make active.
On - positive logic enabled (sink). Connect +24V to a digital input to make active.
A change to this parameter is only implemented if the Drive is disabled or
tripped and the Stop/Reset key is pressed for 1 second.
The Enable and Run terminals should be open when this parameter is
changed.
No. Function Type Limitations Range Units Defaults
31
Stopping
mode
RW U 0 - 3 1 EUR
1USA
No. Function Type Limitations Range Units Defaults
32
Variable
V/f
select
RW Bit On, OFF OFF EUR
OFF USA
No. Function Type Limitations Range Units Defaults
33
Spinning
motor
select
RW U 0 - 3 0 EUR
0USA
No. Function Type Limitations Range Units Defaults
34
Positive
logic
select
RW Bit, R On, OFF ON EUR
ON USA
