Control Techniques DIN1220075A

Dinverter A User Guide
Issue code: d2au9
7
3 Data
3.1 Dinverter
Table 3–1 Power, voltage and current ratings
150% overload output current for 60 seconds maximum
Max. continuous 100% RMS output current (FLC)
Max. continuous 100% RMS AC input current
Continuous motor shaft power
AC supply voltage
Number of
AC supply phases
Model
V kWHPAAA
DIN1220025A 1 200 ~ 240 ±10% 0.25 0.33 3.9 1.5 2.3
DIN1220037A 1 200 ~ 240 ±10% 0.37 0.50 5.7 2.3 3.5
DIN1220055A 1 200 ~ 240 ±10% 0.55 0.75 8.4 3.0 4.5
DIN1220075A 1 200 ~ 240 ±10% 0.75 1.00 11.5 4.3 6.5
Motor
requirements
Number of phases: 3
Voltage: 200V to 240V ±10% (normally delta connected)
Power rating: 0.25kW (0.33HP) to 0.75kW (1HP)
Temperature,
humidity
and cooling
method
Ambient temperature range: –10°C to 50°C (14°F to 122°F). Output
current derating may apply at high ambient temperatures.
Storage temperature range: –40°C to 50°C (–40°F to 122°F)
Humidity: 85% non-condensing
Cooling method: Natural convection
Ingress
protection
Gland plate not fitted: IP00
Gland plate fitted; cable glands not fitted: IP10
Cable-glands fitted: IP20
Overall
dimensions
These dimensions exclude the mounting brackets.
Height: 140mm (5
1
/
2
in)
Width: 75mm (3 in)
Depth: 192mm (7
1
/
2
in)
Weight
Approximate weight of each model: 1.2kg (2lb 11oz)
