PWM switching frequency
0.41 PWM switching
frequency
RW Txt 3 (0)
6 (1)
9 (2)
12 (3)
3
(0)
Motor parameters
0.42 Motor –
number of poles
RW Txt 2P (0)
4P (1)
6P (2)
8P (3)
4P
(1)
0.43 Motor –
power factor
RW Uni 0 ~ 1
0.85
0.44 Motor –
rated voltage
RW Uni 0 ~ 100
% [
AC supply
voltage]
100
0.45 Motor – rated
full-load slip
RW Uni 0 ~ 250 RPM
0
0.46 Motor –
rated current
RW Uni 0 ~ FLC A
FLC
0.47 Motor –
rated frequency
RW Uni
0 ~ ULF Hz
50 (EUR)
60 (USA)
The values entered in these parameters should be obtained from the rating
plate on the motor. Refer to Configuring the Drive for the motor in
Chapter 6.
[0.46] is the total current rating of the motor. The Drive derives the rated
torque-producing (real/active) component of the total motor current from:
[0.46] × [0.43]
Status
0.49 Security status RO Uni (See below)
Refer to Identifying the security status in Chapter 5.
0.50 Software version RO Uni 1.00 ~ 9.99
Software version 02.01.XX is displayed as 2.01
