Dinverter
A
User Guide
Issue code: d2au9
58
Display
The display has four display modes as shown in Table 5–2.
Table 5–2 The four display modes
Display mode Displays... Mode entered by...
Status mode Status of the Drive Normally displayed
Parameter mode Menu number
Parameter number
User pressing the programming keys
Edit mode Value of the selected parameter User pressing the programming keys
Trip mode Trip code Automatically entered
Keypad
Programming keys
These are used for the following:
Changing the mode of operation of the display
Selecting a parameter to edit
Editing the selected parameter
Saving changes to parameter values
The functions of the programming keys are as follows:
and Increase and decrease
Change the display mode
Control keys
By default, the control keys are active only when the Drive is operating in
Keypad mode (except for the RESET key). They are used for the following:
Starting and stopping the motor
Reversing the motor
Resetting the Drive to make new values given to certain parameters
become effective, or after the Drive has tripped.
By changing the settings of certain parameters, the control keys can be
made active or inactive irrespective of the operating mode (terminal or
keypad); see Menu 6.
The functions of the control keys are as follows:
Start the Drive running (RUN)
Stop or reset the Drive (STOP/RESET) (when the Drive
is operating in Terminal mode, it can still be reset using
this key)
Change the direction of rotation of the motor (FWD/REV)
