Dinverter
A
User Guide
Issue code: d2au9
89
Logic table for the security system
The two levels of security are logically related, as follows:
Standard
security
User
security
Conditions
Parameters
that can be
read
Parameters
that can be
edited
Locked Not set up Each time the AC supply is
connected, or the user enters
800 in parameter 0.00
Menu 0
Menu 0
Unlocked Not set up The user enters the number 149
in parameter 0.00
All
All
Locked Locked Each time the AC supply is
connected (subsequent to user-
security being set up), or the
user enters 800 in parameter
0.00
Menu 0
None
Locked Unlocked The user enters the user-security
number in parameter 0.00
Menu 0
Menu 0
Unlocked Locked Each time the AC supply is
connected (subsequent to user-
security being set up), or the
user enters 149 in parameter
0.00
All
None
Unlocked Unlocked The user enters separately the
numbers for the user-
security code and standard-
security code in parameter 0.00
All
All
In all cases, parameter 0.00 can be accessed. See Security procedures later in
this chapter.
