Dinverter A User Guide
Issue code: d2au9
47
A3A3 +10V reference output
Voltage tolerance ±3%
Nominal output current 5mA
Protection Tolerates continuous short-circuit to 0V
A4A4
A5A5
Volt-free relay contact
Function Drive status
Contact rating 2A resistive at 250VAC or 24VDC
Contact resistance 100mΩ maximum
Update time 32ms (30Hz)
Open-contact withstand voltage 750VAC
Voltage isolation from all other circuits in
the Drive
2.5kVAC
(meets IEC664-1 with over-voltage category III)
Operation of the contact Closed
AC supply is applied to the Drive and the Drive is ready to
run (not tripped)
Open
AC supply removed from the Drive, or AC supply is applied
to the Drive and the Drive has tripped
Warning
The relay must not be connected to an
AC supply of over-
voltage category greater than II, as defined in IEC664-1
Insulation co-ordination for equipment within low voltage
systems, section 2.2.2.1.1.
B1B1 0V common
