Dinverter
A
User Guide
Issue code: d2au9
55
3 ×
2.5mm
(14AWG)
2
4 ×
1.0mm
(18AWG)
2
8 ×
0.5mm
(20AWG)
2
RUN FORWARD
RUN REVERSE
DRIVE ENABLE
Speed
reference
0V common
+10V
0V common
5kΩ linear
(2kΩ min)
(Parameter 0.05 set 0 (default).)
Figure 4–16 Temporary connections for bench-testing the Drive
in Terminal mode
