54 M’Ax User Guide
Issue Number: 4
Parameter
Range(
ô )Default( ð )
Type
1.01 {0.03} Value of selected reference +[1.06] RPM RO Bi P
1.03 Pre-ramp reference +
[1.06] RPM RO Bi P
1.04 {0.06} Reference offset +
[1.06] RPM 0 RW Bi
1.05 {0.32} Jog reference 0 ~ 500 RPM 50 RW Uni
1.06 {0.08} Maximum reference clamp
0~n
MAX
RPM
[SLM] RW Uni
1.11 Reference enabled indicator 0~1
RO Bit P
1.12 Reverse selected indicator 0~1
RO Bit P
1.13 {0.31} Jog selected indicator 0~1
RO Bit P
1.14 {0.30} Reference selector 0 ~ 5 1 RO Uni P
1.15 Preset reference selector 0 ~ 4 0 RW Uni P
1.17 {0.34} Keypad reference +
[1.06] RPM RO Bi S P
1.21 {0.33} Preset reference 1 +
[1.06] RPM 1 RW Bi
1.22 Preset reference 2 +
[1.06] RPM 10 RW Bi
1.23 Preset reference 3 +
[1.06] RPM 100 RW Bi
1.24 Preset reference 4 +
[1.06] RPM 1000 RW Bi
1.36 Analog reference +
[1.06] RPM RO Bi
1.42 Preset references selected indicator 0~1
RO Bit
1.43 Keypad reference selected indicator 0~1
RO Bit
1.44 Pulse reference selected indicator 0~1 RO Bit
1.45 Preset reference select bit-0 indicator 0~1 RO Bit
1.46 Preset reference select bit-1 indicator 0~1
RO Bit
1.49 {0.02} Reference selected indicator 1 ~ 5 3 RO Uni P
1.50 Preset reference selected indicator 1~4
RO Uni P
