9.2 Menu 2 parameters
Ramp selection
Software diagram for Menu 2
2.11Acceleration rate 1
2.12
Jog
acceleration
rate
Jog selected
indicator
Acceleration rate 2
Acceleration rate 3
Acceleration rate 4
1.13
2.33
Acceleration-rate
select bit-1 indicator
2.32
Acceleration-rate
select bit-0 indicator
2.13
2.14
2.19
Acceleration
rate selector
1.50
Preset-reference
selected indicator
2.10
0101
0011
1234
Acceleration
rate
2.21Deceleration rate 1
2.22
Jog
deceleration
rate
Jog selected
indicator
Deceleration rate 2
Deceleration rate 3
Deceleration rate 4
1.13
2.36
Deceleration-rate
select bit-1 indicator
2.35
Deceleration-rate
select bit-0 indicator
2.23
2.24
2.29
Deceleration
rate selector
1.50
Preset-reference
selected indicator
2.20
0101
0011
1234
Deceleration
rate
Sequencer
(Menu 6)
Menu 8
Digital input 3
8
DIGITAL I/O
