64 M’Ax User Guide
Issue Number: 4
Notes
The settings of parameter 5.34 are as follows:
0 kgm
2
1 kgcm
2
The settings of parameter 5.54 are as follows:
0 Ranges are as shown for 3.18 and 3.20
1
Ranges are divided by 10
Parameter
Range(
ô )Default( ð )
Type
5.05 {0.43} DC-bus voltage 0 ~ 1000 V RO Uni P
5.07 {0.19} Motor - rated current 0 ~ FLC A [SLM] RO Uni
5.08 Motor - rated speed 0 ~ 7500RPM [SLM] RO Uni
5.09 Motor - rated voltage
0~V
S
[SLM] RO Uni
5.11 Motor - number of poles 0 ~ 255 [SLM] RO Uni
5.12 Flux alignment test enable 0~1 0 RW Bit
5.32 Motor torque-constant 0.00 ~ 500.00 Nm/A [SLM] RO Uni
5.33 Motor inertia
0.1 ~ 6000.0 kgcm
2
or
0.00001 ~ 0.6 kgm
2
[SLM] RO Uni
5.34 {0.11} Inertia units selected 0~1 [SLM] RO Bit
5.54 Inertia range select 0~1 1 RW Bit
FLC
Full-load current
(continuous-current rating of the Drive)
V
S
AC supply voltage
