5 Component data
5.1 Fusing
Table 5-1 Recommended Low Voltage DC supply fuse current ratings (Unidrive
SP size 1 to 3)
Drive
The fuse voltage rating must be suitable for the rectified drive
AC supply voltage, e.g. ≥400Vdc for a SPx20x, ≥750Vdc for a
SPx40x, ≥890Vdc for a SPx50x, and ≥1000Vdc for a SPx60x
F3 (A)
USA fuse
F2a & F2b (A)
European fuse
F2a & F2b (A)
F2c (A)
SP1201 7 8
13A 50Vdc
SP1202 10 10
SP1203 15 16
SP1204 20 20
SP2201 25 25
SP2202 32 35
SP2203 45 50
SP3201 60 63
SP3202 90 100
SP1401 3 4
SP1402 6 6
SP1403 7 8
SP1404 10 10
SP1405 15 16
SP1406 20 20
SP2401 25 25
SP2402 32 35
SP2403 45 50
SP2404 60 63
SP3401 60 63
SP3402 80 80
SP3403 90 100
SP3501 7 8
SP3502 10 10
SP3503 15 16
SP3504 16 20
SP3505 25 25
SP3506 32 35
SP3507 45 50
