CONVAID USER’S GUIDE
Full Torso Swing-Away Support Vest
Adjustable support vest keeps user in place comfortable and securely. Helps maintain mid-
line-seating position and prevent forward slumping. The vest is attached to the chair with
straps that wrap around the seat back and connect with Velcro, and shoulder straps that
screw into the solid seat back. Adjust side straps for proper fit. Fig. 126, 127 & 128
Fig.127
Fig.128
Fig.126
Contoured Firm Headrest (Headwings)
Adjust the headrest height by slightly loosen-
ing the knobs on the seat back, and raising or
lowering the headrest. It can also be pivoted
by changing the horizontal alignment of the
knobs. Fig. 129
Fig.129
Note: Firm Backrest Extension is
recommended when using the
Headwings on the EZ Rider and
Convertible.
Note: All other positioning options
and accessories are utilized on the
planar seating system the same
way as on the standard Cruiser and
EZ Riders. See front of User Guide
for detailed information.
