No. Guard or safety device Function Check
5
(not
shown)
Oven cavity safety ther‐
mostat
Turns off the unit if the temper‐
ature exceeds the allowable
limit
An error code will be output in
the event of a fault
(Contact a service company
that is authorized to reset the
safety thermostat)
6
(installed
by the
customer)
Disconnector
■
Installed close to the unit by
the customer. Easily visible
and accessible, all-pole, with
a contact gap of at least
0.12"
■
Used to de-energize the unit
during cleaning, repairs, and
maintenance work, as well
as in hazardous situations
Procedure:
■
Trip the disconnector
■
Check at the supply termi‐
nals to make sure that the
unit is properly de-energized
Safety measures
The following measures will contribute to greater safety:
Measure Function Check
Unit door solenoid
switch (electrical door
sensor)
■
Stops/turns off the following when
the unit door is opened:
■
Fan (will stop after a few sec‐
onds)
■
Heating element
■
Cleaning agent spraying in the
fully automatic oven cleaning
process
■
Prompts the user to close the unit
door
Test the door solenoid switch with
the combi oven at a low temperature
Procedure:
■
Fully open the unit door
■
Press Start
Result:
The motor must not start running.
Unit door handle with
cracked-open position
■
Prevents steam coming out from
scalding the operator's face and
hands
With the combi oven at a low tem‐
perature, check the door positions
as described in 'Safely Opening and
Closing the Unit Door' in the operat‐
ing manual
Resuming after a power
outage if there was
cleaning agent inside
the unit when the power
went out
■
Starts the fully automatic oven
cleaning process again, from a de‐
fined state, after a power outage
None
3 For Your Safety
Installation Manual 24
