9.4 Heat loss
Heat loss
6.06 mini 6.10 mini 10.10 mini
Heat loss
Latent [BTU/h] 955 1263 1740
Sensible [BTU/h] 1058 1365 1911
9.5 Water connections
Water connections
Water supply (cold only)
Shut-off device The unit may need to be installed with
an appropriate backflow preventer in or‐
der to comply with all applicable federal,
state, and local laws and regulations.
Water supply Two 3/4'' inner diameter GHT-M (gar‐
den hose adapter).
The unit is designed for a permanent
hookup to the water supply that uses a
connecting hose with a minimum diam‐
eter of 1/2"
Flow pressure [psi] 29 – 87 (2 – 6 bar)
Flow pressure (with ConvoClean / Convoclean
+ option)
[psi] 43.5 - 87 (3 - 6 bar)
Water drain
Version Naturally ventilated pipe to open pan or
drain/channel, min. 1" ventilation clear‐
ance
Type [in] Depending on the length of the line and
the elements used in the line, the mini‐
mum inner diameter of the line is 1½” or
2”
Drain temperature [°F] 140
Slope for drain pipe min. 5% (3°)
Safety overflow [inch] 2.36" x 0.79"
9 Technical data
Installation Manual 62
