9.3 Electrical supply
Electrical supply
6.06 mini 6.10 mini 10.10 mini
3~ 208/240 V 60 Hz (3/PE) (for 208 V)
Rated power consumption [kW] 4.5 5.65 8.50
Hot air output (RHK rated output) [kW] 5 6.8 10.2
Motor output [kW] 0.25 0.25 0.25
Rated current [A] 12.5 15.7 23.6
Recommended supply connection
Supply cord 4 wire, two to six feet long AWG 10 10 10
Recommended supply connection: ground wire AWG 10 10 10
Conductor insulation rating SO, SOO, STO, STOO, SEO, SJO,
SJOO, SJTO, SJTOO, SJEO, HSO,
HSOO, HSJO, or HSJOO with or
without suffix W
Permissible connectors NEMA 15-30P or L15-30P
15-50P or L15-50P
Ground fault circuit interrupter (GFCI) according to UL 943 NEC NFPA70
3~ 208/240 V 60 Hz (3/PE) (for 240 V)
Rated power consumption [kW] 5.9 7.45 11.25
Hot air output (RHK rated output) [kW] 5 6.8 10.2
Motor output [kW] 0.25 0.25 0.25
Rated current [A] 14.2 17.9 27.1
Recommended supply connection
Supply cord 4 wire, two to six feet long AWG 10 10 8
Recommended supply connection: ground wire AWG 10 10 8
Conductor insulation rating SO, SOO, STO, STOO, SEO, SJO,
SJOO, SJTO, SJTOO, SJEO, HSO,
HSOO, HSJO, or HSJOO with or
without suffix W
Permissible connectors NEMA 15-30P or L15-30P
15-50P or L15-50P
Ground fault circuit interrupter (GFCI) according to UL 943 NEC NFPA70
9 Technical data
Installation Manual 59
