9.2 Maximum permissible loading weight
Maximum permissible loading weight
The total weight placed on the shelf levels must not exceed the combi oven's maximum permissible
loading weight. For more information on loading details, please refer to the
operating manual:
6.06 mini
6.10 mini
10.10 mini
Maximum load weight
Per combi oven
[lbs]
29
44
66
Per shelf
[lbs]
11
11
11
9 Technical data
Installation Manual
58
57
59
Table of Contents
Table of Contents
5
General
7
Environmental Protection
7
Identifying Your Combi Oven
8
Customer Documentation Structure
9
About this Installation Manual
9
Safety Information that Must be Read Without Exception
10
Configuration and Functions
11
The Combi Oven's Configuration and Functions
11
Control Panel Layout and Functions
13
For Your Safety
14
Basic Safety Instructions
14
Your Combi Oven's Intended Use
16
Warning Labels on the Combi Oven
18
Obligations of Owners and Personnel with the Authority to Issue Instructions in the
20
Hazards Posed by the Unit
21
Safety Devices
23
Staff and Work Area Requirements
25
Personal Protective Equipment
27
Transportation
28
Transporting the Unit to the Installation Location
28
Preparing for Unpacking
28
Included Equipment and Parts
29
Setup
30
Adjacent Systems
30
Installation Location Requirements
31
Removing the Unit from the Pallet (10.10 Mini)
35
Setting up the Unit on a Work Table
36
Setting up the Unit on a Stand
37
Setting up Units in a Stacking Kit
39
Installation
40
Electrical Installation
40
Planning the Electrical Installation
40
Performing the Electrical Installation
42
Network Connection
43
Planning the Network Connection
43
Making the Network Connection
44
Water Connection
45
Water Supply
45
Checking the Water Quality
48
Drain Connection
49
Installing the Convoclean System (for Units with Convoclean / Convoclean+)
51
Components of Fully Automatic Oven Cleaning System
51
Connecting the Fully Automatic Cleaning System
52
Placing into Operation
53
Working Safely When Putting the Unit into Operation
53
Procedure for Placing the Unit into Operation
54
Removing from Service and Disposal
56
Technical Data
57
Dimensions and Weights
57
Maximum Permissible Loading Weight
58
Electrical Supply
59
Heat Loss
62
Water Connections
62
Water Quality
63
Water Consumption
63
Connection Drawings
64
Dimensions and Connection Points (Standard)
64
Dimensions and Connection Points (Easytouch)
68
