4-3. SEARCH - FILE SEARCH
1) Highlight [FILE SEARCH] using (▲)(▼) buttons and press [ENTER] button to select the calendar.
2) The current Calendar Month is displayed, from which a day can be selected.
3) To select another month use the (<<) or (>>) buttons.
4) Days that have recordings stored on the DVR are displayed in green. Days where there are no
recordings stored are displayed in white.
5) Use the Cursor (▲)(▼)(◀)(▶) buttons to select a day, and press the [ENTER] button.
6) The FILE SEARCH window will be shown, use the (<<)(>>)(▲)(▼)(◀)(▶) buttons to highlight the Event
to Play.
Notes on the Display:
The first column shows the File Number.
The second column shows the Date of the File YYYYMMDD
The third column shows the Time that the File started HHMMSS
The fourth column shows the size of the file in seconds.
The Fifth column shows the type of file
The last column shows if the file is Locked (L) or Unlocked (U)
7) Press the [ENTER] button to start the Playback from the start of the recorded File.
8) Press the STOP button to end playback.
[SEARCH]
- TIME SEARCH
- EVENT SEARCH
-< FILE SEARCH>
[SEARCH-CALENDAR]
<< 2005-07 >>
SUN MON TUE WED THU FRI SAT
1 2
3 4 5 6 7 8 9
10 11 12 13 14 15 16
17 18 19 20 21 22 23
24 25 26 27 28 29 30
31
4 < 5 >
Select Month by REW(◀◀) FF(▶▶) buttons
NUM PLAY FILE LIST
082 20050705_121000 170S CU
081 20050705_120000 600S CU
080 20050705_115000 600S CU
079 20050705_114000 600S CU
078 20050705_113000 600S CU
077 20050705_112000 600S CU
076 20050705_111000 600S CU
075 20050705_105000 600S CU
074 20050705_104000 600S CU
073 20050705_103000 600S CU
PAGE 1/13 PGUP:< PGDN:>
4. SEARCH
