10.2.c. Functional parts
A- Locking ring
B- Fastener base
C- Rotating arm
D- Control valve
E- Rotating presser arm
F- Clamping handle
G- Presser roller
H- Accessories fastening
I- Short cone
J- Long cone
K- Bead lift disc
L. Locking pin
F- Presser roller
N- Presser arm
O- Rotation release pin
P- Control valve
Q- Cylinder
10.2.d. Labels placement
Ref. Code Description
1 - Unlocking control plate
2 4-405458 Label, dimensions
3 462081
Label, risk of crushing
1
2
3
2
2
