Corken Z2000 - Appendix C: Performance Charts; Delivery, Brake HP, and Torque Data

Appendix C—Performance Charts
Z2000, ZH2000, ZX2000, and ZXH2000 Coro-Vane
®
Truck Pumps
Pump
Speed
Differential
Pressure
Approximate Delivery of
Propane
1
Brake hp
Required
Pump Torque
Required
RPM psid (kPa) gpm (L/min) bhp (kW) ft•lb (N•M)
750 50 (345) 82 (309) 2.9 (2.2) 20 .4 (27.7)
750 100 (689) 77 (291) 5.8 (4.3) 40.8 (55.3)
750 150
2
(1,034) 75 (284) 8.9 (6.63) 62.2 (84.3)
650 50 (345) 69 (261) 2.5 (1.9) 20 .4 (27.7)
650 100 (689) 64 (242) 5.1 (3.8) 40.8 (55.3)
650 150
2
(1,034) 63 (238) 7.7 (5.7) 62.2 (84.3)
600 50 (345) 63 (238) 2.3 (1.7) 20 .4 (27.7)
600 100 (689) 58 (219) 4.6 (3.5) 40.8 (55.3)
600 150
2
(1,034) 56 (212) 7.1 (5 .3) 62.2 (84.3)
500 50 (345) 52 (197) 1.9 (1.4) 20 .4 (27.7)
500 100 (689) 46 (174) 3.9 (2.9) 40.8 (55.3)
500 150
2
(1,034) 44 (166) 5.9 (4.4) 62.2 (84.3)
Pump
Speed
Differential
Pressure
Approximate Delivery of
Propane
1
Brake hp
Required
Pump Torque
Required
RPM psid (kPa) gpm (L/min) bhp (kW) ft•lb (N•M)
750 50 (345) 112 (424) 6.2 (4.6) 43.4 (58.9)
750 100 (689) 99 (375) 9.9 (7.4) 69.3 (94.0)
650 50 (345) 95 (360) 5.2 (3.9) 42.0 (57.0)
650 100 (689) 84 (318) 8.2 (6.1) 66.3 (89.9)
600 50 (345) 86 (326) 5.0 (3.7) 41.3 (56.0)
600 100 (689) 76 (288) 7.8 (5. 9) 6 4.8 (8 7.9)
500 50 (345) 70 (265) 3.8 (2.8) 3 9.9 (54.1)
500 100 (689) 62 (235) 5.8 (4.3) 60.9 (82.6)
Pump
Speed
Differential
Pressure
Approximate Delivery of
Propane
1
Brake hp
Required
Pump Torque
Required
RPM psid (kPa) gpm (L/min) bhp (kW) ft•lb (N•M)
750 50 (345) 369 (1,397) 12.5 (9.3) 87 (118 .0)
750 100 (689) 325 (1,230) 25.1 (18.6) 175 (2 37. 3)
650 50 (345) 316 (1,196) 10.8 (8.0) 87 (118.0)
650 100 (689) 278 (1,052) 21.7 (16.1) 175 (23 7.3)
600 50 (345) 289 (1,094) 9.9 (7.3) 87 (118 .0)
600 100 (689) 254 (961) 20.0 (14.8) 175 (237.3)
500 50 (345) 236 (893) 8.3 (6.2) 87 (118.0)
500 100 (689) 208 (787) 16.7 (12.4) 175 (237. 3)
Z3200 and ZH3200 Coro-Vane
®
Truck Pumps
Z4200, ZH4200, and Z4500 Coro-Vane
®
Truck Pumps
1
Delivery times are approximate—see note on page 22 for further explanation.
2
Applies to ZX/ZXH2000 models only.
25
