Appendix D—Outline Dimensions for Model Z3200
Eight 7/8" (2.22) diameter holes
2" NPT auxillary inlet
2" NPT
discharge
1/4"
NPT
1/4" NPT
Internal
relief
valve
3" 300 lb ANSI flange inlet
1/4" square keyway
INTERNAL RELIEF VALVE
INSTALLER TO PROVIDE
NOT FOR RECIRCULATING
SET AT 125 P.S.I. MAXIMUM
CORKEN, INC.
A Unit Of IDEX Corp.
SET AT 150 P.S.I.
SEPARATE BY-PASS VALVE
8-3/4
(22.23)
6-3/4
(17.14)
5
(12.70)
3-7/8
(9.84)
14-15/16
(37.94)
10-15/16
(27.78)
4-15/16
(12.47)
1-1/8
(2.86)
17-1/2
(44.43)
1-5/8 (4.13)
3-7/16
(8.73)
5-11/32
(13.57)
2-7/16
(6.24)
1-1/8
(2.86)
8-1/4 D
(20.95)
6-5/8 BC
(16.83)
All dimensions are in inches (centimeters).
