Appendix D—Outline Dimensions for Model Z3500
18.750
(47.6)
1.750
(4.4)
1.750
(4.4)
1.250
(3.2)
1.250
(3.2)
8.435
(21.4)
7.188
(18.3)
5.375
(13.7)
4.125
(10.5)
4.125
(10.5)
3.000
(7.6)
3.000
(7.6)
1.758
(4.5)
1.125
(2.9)
3" NPT
inlet
1/4"
keyway
5.500
(14.0)
7.188
(18.3)
6.813
(17.3)
6.046
(15.4)
3" NPT
outlet
3.25
(8.18)
7.688
(19.5)
All dimensions are in inches (centimeters).
