Corken Z2000 - Page 34

Appendix D—Outline Dimensions for Model ZH3200
Char-Lynn Hydraulics, Inc.
A Division of EATON
6.2 Cubic Inch / Rev
Disc Valve Hydraulic Motor
Model No. 104-1002
INTERNAL RELIEF VALVE
INSTALLER TO PROVIDE
NOT FOR RECIRCULATING
SET AT 125 P.S.I. MAXIMUM
CORKEN, INC.
A Unit Of IDEX Corp.
SET AT 150 P.S.I.
SEPARATE BY-PASS VALVE
1/4" square keyway
3" 300 lb ANSI flange inlet
Hydraulic drive
adapter assembly
Hydraulic motor
1/4" NPT
2" NPT
discharge
Internal relief valve
1/4" NPT
Eight 8-7/8 (2.22)
diameter holes
1-1/8
(2.87)
6-3/4
(17.15)
5-5/16
(13.57)
14-15/16
(37.94)
5
(12.70)
1-5/8 (4.13)
10-15/16 (27.78)
4-15/16 (12.47)
8-3/4 (22.22)
18-1/8 (46.02)
10-15/16 (27.75)
3-7/15
(8.73)
8-1/4D
(20.96)
3-7/8
(9.84)
6-5/8 D B.C.
(16.83)
2-7/16
(6.24)
1-1/8 (2.86)
All dimensions are in inches (centimeters).
34
