Appendix D—Outline Dimensions for Model ZH4200
Hydraulic motor
2" NPT
auxillary
inlet
1/4" NPT
1/4" NPT
Inlet: 4" 300 lb
ANSI flange
5/16" square keyway
Eight 7/8 (2.22)
diameter holes
Outlet: 2" NPT Outlet: 2" NPT
Internal relief valve
Hydraulic drive
adapter assembly
19-9/16
(49.69)
9-3/4
(24.77)
12-3/8
(31.43)
4
(10.16)
8
(20.32)
3-1/4
(8.26)
10-1/8 D
(25.72)
7-7/8 B.C.
(20.00)
7-3/4 (19.69)
16-31/32 (43.08)
7 (17.78)
13-13/16
(35.08)
2-5/8
(6.67)
1-3/16
(3.01)
4
(10.16)
C
C
O
O
R
R
K
K
E
E
N
N
INLET
OUTLET
Char-Lynn Hydraulics, Inc.
A Division of EATON
6.2 Cubic Inch / Rev
Disc Valve Hydraulic Motor
Model No. 104-1002
MODEL
SERIAL
NO.
LISTED 656L
PAT. NOS. 3,072,066 AND 3,392,677
POWER OPERATED PUMP FOR LPG OR ANHYDROUS NH
READ CORKEN INSTRUCTION MANUAL BEFORE OPERATING
OKLAHOMA CITY,OKLAHOMA MADE IN U.S.A.
CORKEN,INC. A Unit Of IDEX Corp.
CORO-VANE
R
2-1/8
(5.40)
1-1/4 (3.18)
All dimensions are in inches (centimeters).
