CPI ARAGON GP - Aragon 25 Km;H

TECHNICAL DATA TD-12
Aragon 25 km/h
Engine:
Nominal power (EEC) 1,5 / 4500 [kW/min
-1
]
Nominal torque (EEC) 3,1 / 4500 [Nm]
Bore / Stroke 40 / 39,2 [mm]
Compression ratio 7,8
Compression pressure (hot) --- [bar/min
-1
]
Piston clearance, max. 0,1 [mm]
Piston ring gap, max. 0,4 [mm]
Fuel supply & adjustments:
Carburetor / Identification no. Dell’Orto PHVA 16 / 08457
Main jet 46
Idling jet 36
Position jet needle 2 [from top]
Float chamber level 13 ± 0.5 [mm]
Air adjustment screw ½ [turns]
Idling speed 2000 ± 100 [min
-1
]
Automatic cold start equipment, stroke at 12V AC
Working time 4
105
[mm/5 min]
[sec.]
Tires & filling pressure:
Front wheel 120 / 70 – 12 51J
Rear wheel 130 / 70 – 12 56J
Air pressure front 1,9 [bar]
Air pressure rear 2,0 [bar]
Filling quantities & specifications:
Fuel (unleaded) 91 ROZ 7,9 [l]
Engine Oil --- [l]
2 stroke oil (full synthetic) 1,4 [l]
Gearbox oil
(SAE 80W90)
100 [ml]
Front fork oil
(SAE 5W20)
100 [ml]
Brake fluid (DOT 4) in case of need
Fuel supply & adjustments:
Carburetor / Identification no. Mikuni VM 16mm Ø
Main jet 47,5
Idling jet 15
Position jet needle 2 [from top]
Float chamber level 14 ± 0.5 [mm]
Air adjustment screw ½ [turns]
Idling speed 2000 ± 100 [min
-1
]
Automatic cold start equipment, stroke at 12V AC
Working time 4
125
[mm/5 min]
[sec.]
CVT:
6,3 [g]
Roller weights
12 x 15 [mm]
