VARIOMATIC TRANSMISSION VT-8
FAST PULLEY
Check the ball bearing and the needle
bearing of the fast pulley for proper
functioning.
Replace the bearings if they do not run
smoothly.
Check the diameter of the fast pulley.
Limit value: 32.90 mm
Fast pulley
CLUTCH SPRING
Measure the free length of the clutch
spring.
Cluch spring length
JR 67 mm 103 mm
Aragon GP 25 km/h 30 / 45 km/h
Aragon 25 / 30 km/h 45 km/h
Formula R 25 / 30 km/h 45 km/h
MOVABLE PULLEY
Measure the inside and the outside
diameter of the movable pulley.
Check the O-rings and the sealing rings
for damage and wear.
Wear limit: 33.10 mm
