VARIOMATIC TRANSMISSION VT-6
MOVABLE DRIVE FACE
Measure the diameter of the sintered
metal sliding bearing.
Wear limit: 21.10 mm
Check the guide sleeve for scuffing,
cracks etc. and replace it if necessary.
Measure the diameter of the guide sleeve.
Wear limit: 20.90 mm
Measure the inside diameter of the clutch
bell housing.
Wear limit: 112.4 mm
Note: Any blue tint of the clutch
bell housing has no negative
effect on the functioning of the
clutch friction.
