CARBURETOR FL-6
Connect the cold start valve to a charged battery
for about 5 min.
Check the additional bore (s. picture).
ok: when you are able to blow in
not ok: when you are not able to blow.
DISASSEMBLY
Release the fastening screws of the choke cable
support bracket and remove the choke cable.
Release the fastening screws of the float chamber
cover and remove the float chamber cover.
When assembling the carburetor float
chamber the seal will probable not fit since
its material takes in fuel so that the seal
swells. In this case the seal shall be dried in the
sun. In most cases it can be reused.
Drive out the float hinge pin with a suitable taper
pin punch. Remove the float with the needle valve.
Unscrew the the main jet, the idle jet, the slide
valve stop screw, and the idle screw.
Clean any deposits or cloggings in the the float
chamber cover and bores with compressed air.
Make sure that all sealing rings and
washers are removed as well. If they
remain in the bores of the carburetor
body, they might get lost during the cleaning
with compressed air.
Danger of injury! Cover the carburetor
with a rag during cleaning and wear
safety goggles!
