Other Features of the Model MC-3 Elite
Note: Only trained technicians should perform these functions.
The Reset Button - This button will reset the operating program. If
the program freezes or stops responding, then pressing this
once will reboot the system. The gauge will not lose calibration
constants, standard counts, or last measurement. However, the
LCD back light and Auto Scroll set will need to be re-enabled.
The scaler will need to be removed from the gauge to use the
reset button. Simply unscrew the four screws on the front of the
panel, lift out of the housing, and turn over the scaler. The reset
button is on the top of the scaler circuit board. See Fig 3.1
RS-232 - This connection will download the constants into the
gauge with the aid of the computer software. Please contact
InstroTek, for more information.
J-45 - This connection is only used at the factory to program the
system software used on the Model MC-3 Elite. Do not plug any
wires to this connection, as it could damage the scalar and will
void any warranty in effect on the gauge.
Display Contrast - This dial sets the contrast of the LCD; this can
be changed to the liking of the user. Using a small screwdriver,
adjust the contrast level.
