Certifications and Standards
UL1741-SA Ed. 2, UL1699B, UL1998, CSA-C22.2
NO.107.1-01, IEEE1547, FCC PART15
IEEE 1547a2014, CA Rule 21, ISO-NE, HECO
Volt-RideThru, Freq-RideThru, Ramp-Rate, Specified-PF,
Volt-VAr, Freq-Watt, Volt-Watt
1) The "Output Voltage Range" and "Output Frequency Range" may differ according to the specific grid standard.
2) Active Power Derating begins at 45°C when PF=1 and MPPT ≥Vmin and at 50°C when PF=1 and MPPT V ≥ 700Vdc.
3) See section 10.3 for further information on operating conditions.
4) Shade Cover accessory required for installation angles of 75 degrees or less.
5) RSD wire-box only includes fuses/fuseholders on the positive polarity, compliant with NEC 2017, 690.9 (C).
6) Fuse values above 20A have additional spacing requirements or require the use of the Y-Comb Terminal Block.
