30
Step 2 Hang the inverter onto the mounting bracket as shown in Figure
3-9 and Figure 3-10:
(a) Lift mounting: Two M10 lifting eye nuts may be installed at the
top of the inverter. Use sling rope or bar (inserted through both
lifting eye nuts) to lift the inverter onto the bracket. The
minimum angle between the two sling ropes should be less
than 90 degrees. NOTE: The M10 lifting eye nuts are not
included with inverter.
(b) Manual mounting: At least two people are required to safely
lift the inverter by the grab handle positions marked in Figure
3-10 and mount it onto the bracket.
CAUTION:
The main enclosure of the CPS SCA25KTL-DO/US-208 3-Phase
String Inverters is approximately 56kg (123.5 pounds). Ensure the
mounting bracket is properly installed and secured before hanging
the inverter on the bracket. It is recommended to have at least 2
people to mount the inverter due to the weight of the equipment.
