Craftsman 113.213213 - Table of Contents; Glossary of Terms

glossary of
1. Workpiece 4.
The item on which the cutting operations is being
performed.
2. DriU Bit or Drill
The cutting tool used in the drill press to make holes
in a workpiece.
3. Backup Material
A piece of wood placed between the workpieceand
table.,.it prevents wood in the workpiecefrom splin-
tering when the drill passes throughthe backside of
the workpiece...also prevents drilling into the table
top.
terms
Revolution Per Minute {R.RM.)
The number of turns completed by a spinningobject
in one minute.
5, Spindle Speed
The RPM of the spindle.
6. Backlash - The amount of handle movement or play
between adjacent moving parts.
table of contents
Page
Warranty.......................................................................... 2
General Safety Instructionsfor Power Tools..................2
AdditionalSafety Instructionsfor DrillPresses ..............3
Glossary ofTerms........................................................... 5
Tableof Contents............................................................ 5
MotorSpecificationsand Electrical
Requirements............................................................. 6
Unpacking and Checking Contents ................................ 7
List of Loose Parts .......................................................... 8
Location and Function of Controls ................................. 9
Assembly ...................................................................... 10
Tools Needed ........................................................... 10
Assembly of Column and Base ............................... 10
Assembly of Elevation worm Gear and Table
Crank ...................................................................... 10
Installing the Table/Support Assembly .....................11
Installing the Head ................................................... 13
Mounting Motor ........................................................ 14
Installing Motor Pulley .............................................. 14
Installing and Tensioning Belt .................................. 14
Installing Belt Guard Knob ....................................... 15
Motor Connections ................................................... 16
Installing Feed Handles ........................................... 16
Installing the Chuck.................................................. 16
Installing Light Bulb .................................................. 18
Bevel Scale .............................................................. 18
Page
Getting to Know Your Drill Press .................................. 19
Spindle Speeds ........................................................ 20
Feature Description .................................................. 20
On-Off Switch ........................................................... 21
Drilling to a Specific Depth ....................................... 22
Locking Chuck Desired Depth .................................22
Removing the Chuck and Arbor .............................. 23
Re-Installing the Chuck and Arbor ...........................24
Basic Drill Press Operation .......................................... 25
Installing Drill Bits in Chuck ...................................... 26
Positioning Table and Workpiece ............................ 26
Tilting Table .............................................................. 27
Hole Location ........................................................... 27
Feeding .................................................................... 27
Adjustments .................................................................. 28
Quill Return Spring ................................................... 28
Quill Bearing Adjustment ......................................... 29
Maintenance ................................................................. 30
Lubrication .................................................................... 30
Recommended Accessories ........................................ 30
Trouble Shooting .......................................................... 31
Repair Parts .................................................................. 32
