Snack / Refreshment Center Setup and Operator's Guide
Page 91670001 April, 1999
Initial Set-Up
If necessary, this merchandiser can be moved through an opening as narrow as 30 inches by removing
panels at the top and bottom of the cabi-
net.
REMOVE THE TOP PANEL:
1. Remove the two screws that secure
each end of the panel to the cabinet.
2. Pull the panel forward to remove it from the merchan-
diser.
REMOVE THE BOTTOM PANEL:
1. Remove the screws that secure the
panel to the cabinet.
2. Pull the panel forward to remove it from the
cabinet.
REMOVABLE PANEL
FOR GETTING THROUGH
A NARROW DOORWAY
VIEW LOOKING INTO THE TOP OF THE CABINET
REMOVABLE PANEL
FOR GETTING THROUGH
A NARROW DOORWAY
VIEW LOOKING INTO THE BOTTOM OF THE CABINET
˜
AB& & 5"C$& - 4$& 5$%241,8*.$%& =4%")D4& 1& ?1%%"#& E""%#1F
