Crane 787E - Page 29

Snack / Refreshment Center Setup and Operator's Guide
Page 231670001 April, 1999
WHEN USED WITH A COUPLER BEARING:
2. Hold the coupler bearing in place and push the spiral coupler through the bearing until the coupler
clicks into position. Be sure the coupler is in the proper orientation as shown.
SPIRAL
COUPLER
SPIRAL
BEARING
