Crane 787E - Selection ID Label Installation (continued); Selection ID Label Placement Guide

Snack / Refreshment Center Setup and Operator's Guide
Page 351670001 April, 1999
A0 A2 A4 A6 A8
A8 A9A0
A1 A2
A3
A4
A5 A6
A7
EXAMPLE OF A BASIC
SNACK TRAY ID LABEL
TO USE
EXAMPLE OF A BASIC
CANDY TRAY ID LABEL
TO USE
WHICH ID LABEL GOES WITH WHICH SELECTION?
See the figures below for snack and candy tray positions.
MOTOR POSITION
TOP TRAY
TRAY A A0 A1 A2 A3 A4 A5 A6 A7 A8 A9
TRAY B B0 B1 B2 B3 B4 B5 B6 B7 B8 B9
BOTTOM TRAY
TRAY C C0 C1 C2 C3 C4 C5 C6 C7 C8 C9
NOTE
This example shows a 3-tray merchandiser.
Some merchandisers can have up to 6 trays.
